The Prognostic Health Management System (PHM) is an Internet of Things (IoT) ecosystem of sensors, infrastructure, data storage, and user interfaces to cost-efficiently:
Measure, Diagnose, Predict, Report and Advise on rotating equipment health.
EQUIPMENT MONITORING PLATFORM (IoT)
ALARM MANAGEMENT & 24/7 SUPPORT
AI-ASSISTED EXPERT DIAGNOSIS & REPORTING
equipment vital signs such as, temperature, vibration, pressure, current usage, resistance, and others are placed at strategic points on the rotating equipment.
iMotorlinx wireless temperature sensor
Depending on the types of sensors (wireless or wired) different network hardware is used to transmit the sensor data to be processed.
Zigbee data Gateway
To support specific security requirements, either a private server or cloud based platform is used for data storage and processing. AWS is our go-to cloud platform.
Cloud Platform (AWS) or Private
iMotorlinx proprietary software processes the data, supports both manual and automated analysis through AI and prepares the data for alarm notification and reporting.
Prognostic & Health Management (PHM) Dashboard
Large Screen
PC
Mobile
Running Condition
Alarm Management
Asset Insight
AI Diagnosis
Health Index
Maintenance Forecast
Life Prediction
Message Center
Asset Profile
3D Modelling
Online Inspection
Spare Parts
Operation Recommendation
Expert Assistance
Fault Diagnosis Models
Health Assessment Models
Life Prediction Models
IoT Hub
Big Data Center
Algorithm Center
Digital Twin
Cloud Infrastructure (Support On-Prem & Cloud Migration)
Sensor (A)
Sensor (B)
Wired Sensor
Controller
Gateway
Relay
Motor
VFD
Compressor
Fan
Pump
Other Rotating Equipment
The software supports multiple warning modes, such as threshold alarms, trend alarms, and frequency band alarms. An expert is only one-click-away with our 24/7 support team. This ensures the quickest response to any issue.
Equipment health diagnosis and fault diagnostics reports are generated online to help users quickly locate and solve problems.
Reports include all the essential topics to help the O&M teams understand the issue and the advised follow-up.
Contact us today to learn how our smart lifecycle management solutions can
transform your operations
